• Kingston 4GB DDR3 1600MHz (PC3-12800) CL11 SODIMM Memory


  • SKU: D3SO-4G1600KING11
  • EAN: 7.41E+11
  • Availability: 5+ In Stock
  1 people view today
  • Memory Capacity : 4GB
  • Memory type: SODIMM
  • Warranty : Lifetime
  • $44.23

Product Detail

ValueRAM's 512M x 64-bit (4GB) DDR3L-1600 CL11 SDRAM (Synchronous DRAM), 1Rx8, low voltage, memory module, based on eight 512M  x 8-bit FBGA components. The SPD is programmed to JEDEC standard latency DDR3-1600 timing of 11-11-11 at 1.35V or 1.5V. This
204-pin SODIMM uses gold contact fingers.
Capacity4GB
Memory Model Kingston ValueRAM
Rank R1 Single Rank
Memory TypeSODIMM
CompliancePC3-12800
Error Correction

Non-ECC Unbuffered

Memory Speed

1600MHz

CAS Latency

CL11

WarrantyLifetime

Features

• JEDEC standard 1.5V (1.425V ~1.575V) Power Supply
• VDDQ = 1.5V (1.425V ~ 1.575V)
• 800MHz fCK for 1600Mb/sec/pin
• 8 independent internal bank
• Programmable CAS Latency: 11, 10, 9, 8, 7, 6
• Programmable Additive Latency: 0, CL - 2, or CL - 1 clock
• 8-bit pre-fetch
• Burst Length: 8 (Interleave without any limit, sequential withstarting address “000” only), 4 with tCCD = 4 which does not allow seamless read or write
  [either on the fly using A12 or MRS]
• Bi-directional Differential Data Strobe
• Internal(self) calibration : Internal self calibration through ZQ pin (RZQ : 240 ohm ± 1%)
• On Die Termination using ODT pin
• Average Refresh Period 7.8us at lower than TCASE 85°C 3.9us at 85°C < TCASE < 95°C
• Asynchronous Reset
• PCB : Height 1.180” (30.00mm), double sided component
ManufacturerKingston
ColorNo
BuyBack Product SKUNo
Supported Memory TypesDDR3-SDRAM
Memory Layout (Modules X Size)4GB (1 X 4GB)
Memory Clock Speed1600MHz To 1749MHz
Internal Memory (RAM)4GB
Internal Memory TypeDDR3-SDRAM
Memory PinsNo
CAS LatencyNo
RefurbishedNo
ConditionBrand New
