| Motherboard Brand |
ASRock |
| Chipset |
Intel® H610 |
| Form Factor |
Micro ATX Form Factor (8.66-in x 7.6-in / 22.0 cm x 19.3 cm) |
| CPU Support |
Supports 12th Gen, 13th Gen, and subsequent Gen Intel® Core™ Processors (LGA1700)
Supports Intel® Hybrid & Turbo Boost Max 3.0 Technologies |
| Power Phase Design |
Robust 6+1+1 Power Phase Design (Smooth CPU power delivery) |
| Memory Specifications (DDR5) |
Dual Channel DDR5 Memory Technology (2 x DDR5 DIMM Slots)
13th Gen CPUs: Support non-ECC un-buffered memory up to 5600MHz
12th Gen CPUs: Support non-ECC un-buffered memory up to 4800MHz
Max. Capacity: 96GB | Supports Intel® Extreme Memory Profile (XMP) 3.0 |
| Expansion Slots |
CPU: 1 x PCIe 4.0 x16 Slot (PCIE1, supports x16 mode)
Chipset: 1 x PCIe 3.0 x1 Slot (PCIE2)
*Supports NVMe SSD as boot disks |
| Storage Connectors |
1 x Ultra M.2 Socket (Key M, Type 2242/2260/2280 PCIe Gen3x4 up to 32 Gb/s)
4 x SATA3 6.0 Gb/s Connectors |
| Graphics & Video Outputs |
Intel® Xe Graphics Architecture (Gen 12)
1 x HDMI 2.1 TMDS (Max. Resolution 4K @ 60Hz)
1 x DisplayPort 1.4 with DSC (Max. Resolution 8K @ 60Hz / 5K @ 120Hz)
1 x D-Sub (Max. Resolution Full HD 1920x1080 @ 60Hz)
*Supports Triple Graphics Outputs simultaneously (Requires CPU with Integrated Graphics) |
| Audio System |
7.1 CH HD Audio (Realtek ALC897 Audio Codec) |
| LAN Connectivity |
Gigabit LAN 10/100/1000 Mb/s (Realtek 8111H) |
| USB Interface |
Rear: 1 x USB 3.2 Gen1 Type-C, 1 x USB 3.2 Gen1 Type-A, 4 x USB 2.0
Front Headers: 2 x USB 3.2 Gen1 Ports, 2 x USB 2.0 Ports
*All USB ports support ESD Protection |
| Internal Headers & Cooling |
1 x SPI TPM | 1 x Chassis Intrusion & Speaker | 1 x Addressable LED Header (5V)
1 x 4-pin CPU Fan (1A/12W) | 1 x 4-pin Chassis/Water Pump Fan (2A/24W)
1 x 24-pin ATX Power | 1 x 8-pin 12V Power | 1 x Front Panel Audio |
| Rear Panel I/O Ports |
1 x PS/2 Mouse/Keyboard Port
1 x D-Sub | 1 x HDMI | 1 x DisplayPort 1.4
1 x USB 3.2 Gen1 Type-C | 1 x USB 3.2 Gen1 Type-A | 4 x USB 2.0 Ports
1 x RJ-45 LAN Port | HD Audio Jacks: Line in / Front Speaker / Microphone |
| RGB & Software Eco-System |
ASRock Polychrome SYNC (Addressable RGB Header supports up to 5V/3A, 80 LEDs)
ASRock Motherboard Utility (A-Tuning) & ASRock XFast LAN |
| EZ Update & UEFI |
ASRock Auto Driver Installer (Pre-installed LAN driver for easy updates)
ASRock EZ Mode, Full HD UEFI, My Favorites, & Instant Flash |
| Operating System & Certifications |
Microsoft® Windows® 10 64-bit / 11 64-bit
FCC, CE, ErP/EuP ready |
| Box Accessories |
1 x User Manual, 1 x I/O Shield, 2 x SATA Data Cables, 1 x Screw for M.2 Socket |
| Condition |
Brand New |
