Asrock A520M-HDV, AMD A520, AM4, Micro ATX, 2 DDR4, VGA, DVI, HDMI, M.2

£90.99

In stock

Only 2 left

SKU

A520M-HDV

Key Features

Product Details
Type	Desktop
Socket	AMD AM4
Form Factor	Micro ATX
Chipset	AMD A520
CPU Support	*Note: not compatible with Ryzen 5 3400G & Ryzen 3 3200G CPUs
Maximum Memory	64GB
RAM Slots	2 x DIMM
RAM Speed	4733+(OC) / 4666(OC) / 4600(OC) / 4533(OC) / 4466(OC) / 4400(OC) / 4333(OC) / 4266(OC) / 4200(OC) / 4133(OC) / 4000(OC) / 3866(OC) / 3800(OC) / 3733(OC) / 3600(OC) / 3466(OC) / 3200 / 2933 / 2667 / 2400 / 2133 MHz
Graphics	Integrated Graphics Processor
Graphics Port	1 x HDMI 1 x VGA
PCI/PCI Express	1 x PCIe 3.0 x16 Slot (PCIE2: x16 mode) 1 x PCIe 3.0 x1
USB Ports Supported	6 x USB 3.2 Gen1 (4 at back, 2 at mid-board) 6 x USB 2.0 (2 at back, 4 at mid-board)
Storage	4 x SATA III 1 x M.2 (2242/2260/2280) - SATA & PCIe
LAN	GB LAN
Back Panel I/o Ports	1 x PS/2 Mouse/Keyboard 1 x D-Sub 1 x DVI-D 1 x HDMI 2 x USB 2.0 4 x USB 3.2 Gen1 1 x RJ-45 LAN HD Audio Jacks
Internal I/O Connectors	1 x SPI TPM 1 x COM Port 1 x Chassis Intrusion and Speaker 1 x CPU Fan 2 x Chassis Fan 1 x 24 pin ATX 1 x 4 pin 12V 1 x Front Audio 2 x USB 2.0 1 x USB 3.2 Gen1
Accessories	2 x SATA Data Cables 1 x Screw for M.2 Socket
Package Weight	0.7920 kg
Warranty	2 Year Replacement Warranty
Condition	Brand New

Supports 3rd Gen AMD AM4 Ryzen™ / Future AMD Ryzen™ Processors(3000 and 4000 Series Processors)
6 Phase Power Design
Supports DDR4 4733+ (OC)
1 x PCIe 3.0 x16, 1 x PCIe 3.0 x1
Graphics Output Options: D-Sub, DVI-D, HDMI
7.1 CH HD Audio (Realtek ALC887 Audio Codec)
4 x SATA3, 1 x Ultra M.2(Gen3 x4 & SATA3)
6 x USB 3.2 Gen1(4 x Rear, 2 x Front)
6 x USB 2.0(2 x Rear, 4 x Front)
Realtek Gigabit LAN
