• Asus X299-WS SAGE, Workstation, Intel X299, 2066, CEB, DDR4, 7 x PCIe, Dual M.2 & U.2, Dual LAN


  • SKU: AUMBX299SAGE-WS
  • EAN: 4712900853674
  • Availability: 11+ In Stock
  • Type: Server / Workstation
  • Form Factor: CEB
  • Chipset: Intel X299
  • Maximum Memory: 128GB
  • Intel HD Graphics
  • 3 Years Warranty
  • $805.04

 Product Details :

Type
Server / Workstation
Socket2066
ChipsetIntel X299
Maximum Memory128GB DDR4
RAM Speed
4200(O.C.)/4133(O.C.)/4000(O.C.)/3600(O.C.)/2666/2400/2133 MHz
Memory TypeDDR4 (Quad Channel)
Storage8 x SATA III
1 x M.2 Socket (2242/2260/2280/22110) - PCIe
1 x M.2 Socket (2242/2260/2280) - PCIe
2 x U.2
GraphicsIntel HD Graphics
Multi GPU SupportSupports NVIDIA 4-Way SLI Technology
Supports AMD 4-Way CrossFireX Technology
Graphics Port1 x VGA
1 x HDMI
1 x DisplayPort 1.2
Audio
Realtek ALC S1220A 7.1-Channel High Definition Audio CODEC
USB Port Supported

2 x USB 3.1 Gen 2 , 8 x USB 3.1 Gen 1 ,4 x USB 2.0

1 x USB 3.1 Gen 2 front panel connector ,

Internal I/O connectors2 x U.2 port
1 x AAFP
1 x Aura RGB Strip
1 x USB 3.1 Gen1
2 x M.2 Socket 3
1 x TPM
1 x COM port
8 x SATA
1 x VROC_HW_Key
1 x CPU Fan
1 x CPU OPT Fan
2 x Chassis Fan
1 x AIO_PUMP
1 x Thunderbolt
1 x 24-pin EATX
1 x 6-pin ATX
2 x 8-pin ATX 12V
1 x EZ XMP switch
1 x 5-pin EXT_FAN
1 x Water Pump
1 x System panel
1 x USB 3.1 Gen 2 front panel
1 x CPU_OV jumper
1 x M.2 Fan Header
1 x Aura Addressable Strip Header
Back Panel I/o Ports2 x LAN (RJ45)
2 x USB 3.1 Gen 2
6 x USB 3.1 Gen 1
4 x USB 2.0
1 x Optical S/PDIF out
1 x USB BIOS Flashback Button
1 x 8-channel Audio I/O
PCL Express
2 x PCIe 3.0 x16 (x16 mode)
2 x PCIe 3.0 x16 (Single at x16dual at x8/x8)
1 x PCIe 3.0 x4 (x4 mode)
LANDual GB LAN
ButtonsClear CMOS , Reset , Power On
Package Weight2.8000 kg
AccessoriesASUS Q-Shield
1 x Vertical M.2 brackets
1 x COM port cable
8 x SATA cables
1 x M.2 screws
1 x MOS Cooling kit
3-Way & 4-Way SLI bridge
1 x SLI HB BRIDGE
1 x Q-Connector
Warranty3 Years
Condition New

Intel LGA 2066 CEB motherboard with quad-strength graphics supports, DDR4 4133MHz, dual M.2 & U.2, USB 3.1 Gen 2 connectors, and ASUS Control Centre
  • 4-Way PCI-E Gen3 x16 link supporting NVidia GeForce SLI® and AMD CrossFireX™ on demand.
  • Ultra-efficient VRM heatsink: Metal fin array connected to large surface area via a heatpipe tames X299 thermals to enable unthrottled performance.
  • 5-Way Optimisation: One-click, system-wide tuning, delivers optimised overclocking and intelligent cooling for a diverse range of workloads.
  • Industry-leading cooling options: Comprehensive controls for fans and water pumps, via Fan Xpert 4 software or the acclaimed ASUS UEFI
  • ASUS Control Centre: A software utility that provides convenient, secure and cost-saving centralized IT management for small and medium businesses.
  • Next-gen transfer speeds: Up to 32Gbps dual M.2 and U.2, plus up to 10Gbps USB 3.1 Gen 2 Type-A and Type-C front connector
ManufacturerAsus
ColorNo
BuyBack Product SKUNo
Motherboard Form FactorCEB
ChipsetIntel X299
Motherboard TypeServer/Workstation
Processor Socket2066
RAM TechnologyDDR4 (Quad Channel)
Graphics ProcessorIntel
RAM Slots8 X DIMM
Maximum Memory128GB
RefurbishedNo
ConditionBrand New
